HEGENSCHEIDT U2000-400 - Underfloor wheelset reprofiling up to 400kn axle load

Economical and high-precision machining of wheelsets, both for high-speed trains and for local trains in installed and removed condition, are the core competencies of our underfloor wheelset turning machines.  Thanks to the two different sizes 150 and 400, wheelsets with a running circle diameter of min. 350 mm and max. 1400 mm can be reprofiled. Naturally, the modern underfloor wheelset lathes meet all currently known working and precision requirements and their overall design is also geared towards future developments. As pioneers in wheelset reprofiling, our machines currently represent the highest standard in wheelset machining technology.

Application and use



The CNC-controlled U2000-400 is a universally applicable, dynamically rigid and particularly operator- and service-friendly underfloor wheelset turning machine for reprofiling wheelsets in mounted and dismounted condition for axle loads of up to 400kN. Wheel and shaft brake disks can also be processed on the machine.

The machine guarantees optimum cost-effectiveness thanks to its high degree of utilization, precision, long service life, and low maintenance costs. The compact machine layout and integrated control cabinet ensure a small footprint and user-friendly installation requirements.













Added value

  • State of the art reprofiling of tram and metro wheelsets, both mounted and demounted
  • Optimum cost-effectiveness thanks to high utilization rates, precision, long life, and low maintenance costs
  • Ergonomic and simple operation through a central control panel with direct access to all machine functions
  • Automatic processing to reduce the operator‘s workload and guarantee precision
  • Reliable protection against flying chips during machining
  • Simple chip disposal thanks to integrated chip removal plates
  • Long-lasting accuracy of the guideways for the supports
  • Environmentally friendly grease lubrication of the supports
  • Compact machine layout
  • Modular design enables subsequent data exchange with other systems or subsequent expansion of the machine

Function

The U2000-400 is suitable for turning the treads up to the crown of the wheel flange and the back of the wheel flange, reprofiling and partial reprofiling of wheelsets, machining the inner and outer wheel faces, reprofiling wheelsets single-sided, machining shaft brake disks and / or wheel brake disks and other options according to technical agreement.

The U2000-400 is operated via a central control panel, which provides optimum access to all machine functions in a suitable working position. At the same time, the operator is safely protected against flying chips during machining. The integrated automatic machining system relieves the operator and ensures simple control.

For simultaneous machining of wheelsets in bogies with mechanically uncoupled axles, a tandem version U2000-400D is also available.



Highlights of the U2000-400

Machine specification

Machine data
Machine dimensions (L x W x H) 5,500 mm x 2,400 mm x 2,300 mm
Pit dimensions (L x W x H) 8,000 mm x 7,000 mm x 2,300 mm
Machine weight 18 t
Power (per machine) 96KW
Optional Equipment

  • Machining of wheel brake discs
  • Machining of internal and external shaft brake discs
  • Smoke extraction
  • Machining of mechanically coupled wheelsets
  • Slip monitoring
  • Database management
  • Automatic lubrication
  • Shifting vehicle
Accuracies profile machining
Maximum difference in diameter between the both wheels of a wheel set* ≤ 0.1 mm
Maximum difference in diameter between the wheels of a bogie* ≤ 0.3 mm
Maximum radial runout* ≤ 0.1 mm
Maximum axial runout at inner flange crest ≤ 0.2 mm
Profile shape deviation  ≤ 0.2 mm
Profile surface roughness Rz ≤ 63 µm
Surface quality on sides of the wheel profile ≤ 100 µm
Maximum chip cross-section per support 10 mm²
Wheelset dimensions
Maximum running circle diameter** 1,400 mm
Minimum running circle diameter** 350 mm
Axle lenghts  1,600 ... 2,600 mm (for track width 1,435mm)
Profile width 75 ... 100 mm
Track width 1,000 ... 1,676 mm
Maximum axle load 400 kN
Accuracies break disc machining
Axial runout ≤ 0.2 mm
Surface flatness ≤ 0.1 mm / 100 mm
Surface roughness Rz ≤  16 µm

* for solid wheels ** other maximum diameters possible after request

view more

Success story with the Karlsruhe public transport company

We were guests at the Karlsruhe transport company and took a look behind the scenes. This is where our U2000-400 underfloor machine is used for machining wheelsets for streetcars. The modern underfloor wheelset turning machine not only meets all current working and precision requirements, but its overall design is also geared towards future developments. It represents the current state of the art in wheelset machining technology and also ensures efficient and precise maintenance and servicing of the fleet at Karlsruhe's public transportation company with several machines in operation.



Brochure

Here you will find all the contents of the U2000-400 as a download.

DOWNLOAD | PDF 1.56 MB
