Mobile Wheelset Lathe

HEGENSCHEIDT MOBITURN®3 - On-demand wheelset maintenance

Our MOBITURN®3 mobile above-ground wheelset turning machine is designed to guarantee precise, on-demand vehicle maintenance with short downtimes and high vehicle availability. The world's first and only mobile wheelset turning machine, now in its 3rd generation, takes the technology of the underfloor wheelset turning machines and brings it to the rail vehicle as a mobile system.

Application and use

Mobiturn®3 is a mobile wheelset turning machine for on-demand maintenance of rail vehicle wheels, wheelsets, and brake discs in both mounted and demounted condition. It is the world‘s first and only system that comes to the rail vehicle. The Mobiturn®3 can be transported by rail or road to different locations. This ensures minimal downtime and high vehicle availability. In addition to increased effciency in the cost-intensive maintenance of rail vehicles, the Mobiturn also offers exceptional quality and flexibility. HEGENSCHEIDTs many years of experience as the market leader in wheelset maintenance and the proven design basis of a classic underfloor lathe machine pay off here. The patented MOBITURN is now in its 3rd generation and has been extensively revised in both design and appearance. It combines state of the art technology with modern design.

Added value

Mobile wheelset maintenance that comes to the rail vehicle
Maximizes maintenance cost-effectiveness by minimizing downtime and maximizing vehicle availability
Available as a delivery product or as an operator model
Processing of wheelsets from 350 mm diameter and up to center distances of 1.200 – 3.600 mm
Modular design for customized configuration (e.g. individual conﬁguration of chip crusher, -conveyor, and -carriage, chassis, operator‘s platform, fume extraction,
central lubrication)
Optional measurement technology with suitability test (probe to achieve extended uncertainty of measurement K=2)
Optional clamp manipulator for easy handling of clamps / hold-down devices
Compact wheelbase for tight curve radii
Improved fume extraction, accessibility, and ergonomics, especially at the operator‘s workstation
Optimized heat management
Maximum CNC performance and standardization of maintenance and engineering tasks using advanced software tools

Function

The components on the machine's frame have been rearranged to give the MOBITURN a more compact wheelbase. This makes the machine more flexible in track curves and improves the individual positioning of the machine in the customer's track. The new layout also allows the hydraulics to be moved to the rear of the machine, making the valve terminals more accessible and improving the overall thermal management of the machine. The redesigned roller carriers can now handle wheelsets from 350mm diameter. The machine can be optionally equipped with an automatic lubrication system. This includes the most important components such as: chip breaker, roller carriers, axial rollers, and supports. This reduces maintenance and the risk of insufficient lubrication. Optionally, the system can be equipped with a measuring probe to achieve the extended measurement uncertainty (K=2). On the control side, the modern and powerful SIEMENS SINUMERIK-ONE CNC control is used. HEGENSCHEIDT's newly developed operating software, based on the C++ programming language and the modern Qt application framework, is used to operate the machines.

Highlights of MOBITURN®3

Machine specification

Machine data
Machine dimensions (L x W x H)	8,832 mm x 2,620 mm x 1,632 mm (incl. chip container)
Machine weight	17 t
Power (per machine)	50 KVA
Accuracies
Maximum difference in diameter between both wheels of a wheel set*	≤ 0.1 mm
Maximum difference in diameter between the wheels of a bogie*	≤ 0.3 mm
Maximum radial runout*	≤ 0.1 mm
Maximum chip cross-section per support	6 mm²
Wheel set dimensions
Minimum running circle diameter**	350 mm
Maximum running circle diameter**	1,450 mm
Center distance	1,200 - 3,600 mm
Software
Control system	Siemens Sinumerik ONE
Application and operating software	1,500 TIA-PLC (Totally Integrated Automation-PLC) HMFD's own application and operating software AIC-HMI (Artificial Intelligence Control - Human Machine Interface)

* for solid wheels

Brochure

Here you will find all the contents of the MOBITURN®3 as a download.

DOWNLOAD | PDF 1.74 MB
